Gold3

Gold3

The Gold3 uses a four piece OTL cantilever with a Grado specific elliptical diamond stylus mounted on a brass bushing. A machined turned generator is used to achieve a lower...

Regular price $260.00
Sale price $260.00 Regular price
OFF Sold out
Shipping calculated at checkout.

Type:

Cartridges

Many in Stock

View full details
The Gold3 uses a four piece OTL cantilever with a Grado specific elliptical diamond stylus mounted on a brass bushing. A machined turned generator is used to achieve a lower distortion and greater transparency.

Grado’s OTL, or optimized transmission line, technology provides an ideal transfer of signal from the surface of the LP to the generator of the system.

This technology rejects unwanted resonances and lowers distortion preserving the fundamental and harmonic frequencies of the music. This also helps keep noise generated by the motor system in the cartridge to a minimum.

Grado’s OTL stylus/cantilever design makes records sound quieter, improves the height, width, and depth of the soundstage, and present more detail than previously obtainable.

The Gold3 are all hand assembled by our team in Brooklyn, with some builders having over 25 years of experience. With the recent development of the highly received Lineage Series of cartridges, we were able to have a trickle down of technology and bring some new techniques to the Gold3.

This updated series of cartridges offers excellent tonal balance, dynamics, and realism, for a most rewarding reproduction of vocals and instruments. Our coil winding techniques, using ultra high purity copper wire which were honed during the development of the Lineage Series, have let the electrical circuits achieve unison between the four coils in each phono cartridge. This allows for a precise balance between channels and accurate stereo imaging.

As in all Grado phono cartridges the Gold3 is powered by a twin magnet system that optimizes the balance between stereo channels. All internal magnetic circuit parts are held to extremely high tolerances creating the desired stereo imaging. Grado’s patented Flux-Bridger design allows the Gold3 to have one of the lowest effective moving mass generating systems while creating an excellent balance throughout the full frequency range.

  • Output - 4 mV @ 5 CMV (45 degrees)
  • Frequency Response - 10-55,000 Hz
  • Channel Separation - Average 25 DB, 10-30,000 Hz
  • Stylus - Diamond- Elliptical
  • Input Load - 10k - 47k ohms
  • Induction - 50 mH
  • DC Resistance - 660 ohms
  • Cartridge Weight - 6 grams
  • Tracking Force - 1.6 -1.9 grams
  • Compliance - 20 um/mN
  • Mounting - P-mount or 1/2’’ Screw Mount

Customer Reviews

Based on 38 reviews
97%
(37)
3%
(1)
0%
(0)
0%
(0)
0%
(0)
J
Jeff Danielson
Excellent

Like many others these days I've been rediscovering my turntable and lp collection, and the Gold3 has certainly elevated that experience. My new Denon amp and Klipsch sub have helped a lot also. But the Gold3 gives me so much more breadth and depth in the low end and smoothness and clarity at the high end my old cartridges pale in comparison. Gone are the harsh highs and present for the first time is a wonderful even breadth of lows so that lps that I'd given up on sound greater than ever before. Now if I can just resurrect my old Goldring/Lenco turntable I'll be in the proverbial hog heaven. My Dual is really just fine, but....... :)

A
Alfred Turner
Great sound for a reasonable price

Replaced my old Shure Type V with the Gold 3 and was immediately inspired by the sound to dig out my many classical, Americana, and jazz albums.
Tight bass, warm mid range, and a nice top end. Each instrument (or section of the orchestra) well defined. Piano is particularly lovely.
Bonus: even my vintage rock albums sound fresh.
Only complaint: the mounting screws. My Shure came with a variety from which I could chose the best to fit my finicky Thorens tone arm wand. Not so the Grado, which made mounting it a trial.

R
Ross Powell
Gold3

Exceed my expectations, wonderful separation of tracks, magnificent high end response, vivid low end. Makes me wish I had upgraded my cartridge years ago!
Highly recommended.

J
John G.
The Grado house sound, updated.

I started using Grado cartridges in 1970 and so their “house sound” is comforting. All may favorite albums have the Grado sound print in my head. I’ve owned all the major brands and a few esoteric ones but always return to what I know and love. The Gold3 is perfect and a bargain at this price point… high output is easy on the electronics. The best part is the music, acoustic instruments and voices sound natural and organic, not amped up or muted down, just like they are suppose to. Rhythm is spot on, not appearing to race or fall asleep. The Gold3 is the opposite of a showy showroom sound, no bonus splash or slam, just the music.

E
E.C.

excellent
